O – Lattice Beam of Ringlock Scaffolding

O – Lattice Beams can be fabricated with welded ledger heads at both ends and are easily assembled on-site using the Ringlock Rosette system, saving time and reducing costs. Alternatively, O – Lattice Beams can also be set up with clamps directly, offering flexibility in different applications.
We offer a ring lock scaffold standard system that complies with EN 12811-1 and OSHA standards, and its size, thickness and surface treatment are fully customizable. Please request a quotation to learn about tailor-made solutions.

Material: Q235 / S235JR
Surface Treatment: Hot-dip Galvanized
Diameter: 48.3mm
Thickness: 3.2mm / 3.0mm
Length: 1.8-6.14m
Product Code: RLB180 – RLB614

Add to quote
SKU： RLB180-RLB614 分类： 标签： , , , , , ,

Code# Length Material Diameter Thickness Note
cm mm inch mm mm
RLB180 180 1800 5’11” Q235/S235JR 48.3 3.2/3.0 A
RLB200 200 2000 6’6” A
RLB207 207 2070 6’10” B
RLB257 257 2570 8’5” B
RLB300 300 3000 9’10” A
RLB307 307 3070 10′ B
RLB360 360 3600 11’10” A
RLB400 400 4000 13’1” A
RLB414 414 4140 13’7” B
RLB500 500 5000 16’5” A
RLB514 514 5140 16’10” B
RLB600 600 6000 19’8” A
RLB614 614 6140 20’2” B

*Note “A” O-Lattice Beam length are commonly used in Asian and African markets;

*Note “B” O-Lattice Beam length can be replaced by European and American brands.
